HP Z400 User Manual

◦
Memory size and configuration
◦
Processor information
◦
Storage device information and configuration
◦
Graphics / audio / communications information and configuration
◦
And more...
●
Comprehensive list of diagnostic test available with new added features:
◦
Highly configurable testing options: quick / complete / custom / interactive / non-interactive
◦
Specific failing memory DIMM identification
◦
Tests video card memory
◦
Launches DST Smart tests for both SATA and SAS drives
◦
Many other tests and diagnostics
●
Diagnostic Failure Code Output – A unique warranty code is generated for each failure which can
be used to validate diagnostic use for a specific system
●
Easy to use - uses similar user interface as previous field diagnostics, HP Insight Diagnostics
●
True End2End diagnostics – same diagnostics modules used in factory
●
Easy to obtain:
◦
Download from Web
◦
Bootable via USB flash drive, DVD, or CD
◦
Included with restore media
Please run Vision diagnostics on supported products when attempting to troubleshoot system issues.
Overview
The HP Vision Diagnostics utility lets you view information about the hardware configuration of the
workstation and perform hardware diagnostic tests on subsystems. The utility simplifies the process of
effectively identifying, diagnosing, and isolating hardware issues.
Invoke HP Vision Diagnostics to display the Survey tab. This tab shows the current configuration of the
workstation. From the Survey tab, you can access several categories of information about the
workstation. Other tabs provide additional information, including diagnostic test options and test
results.
Use HP Vision Diagnostics to determine if the system recognizes all the devices installed on the
workstation and if the devices function properly. HP recommends that you run these tests after you
install or connect new devices.
You can save the information from each diagnostic screen to an HTML file. You should run tests, save
the test results, and print them so that you have a report available before placing a call to the Customer
Support Center.
NOTE: HP Vision Diagnostics may not detect third-party devices..
ENWW
Self-troubleshooting with HP Vision Diagnostics
185

HP Z400 Specifications

General

Bus type	QPI
Processor cache	4 MB
Processor cores	2
Processor model	W3503
System bus rate	4.8 GT/s
Processor socket	-
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Number of processors installed	1
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	24 GB
Audio system	Realtek ALC262
Product type	Workstation
Motherboard chipset	Intel® X58 Express
Memory slots	6x DIMM
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1066 MHz
Memory layout (slots x size)	- GB
Graphics card	Quadro 600
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
HDD speed	- RPM
RAID levels	0, 1, 5, 10
HDD capacity	500 GB
HDD interface	SATA II
Storage media	HDD
Display included	No
USB 2.0 ports quantity	8
Parallel ports quantity	0
Chassis type	Minitower
Country of origin	China
Number of 5.25\" bays	3
Operating system installed	Windows 7 Professional
Operating system architecture	32-bit
Power supply	475 W
Processor ARK ID	40800
Processor package size	42.5 x 45 mm
Supported instruction sets	SSE4.2

Weight and Dimensions

Depth	455.3 mm
Width	167.9 mm
Height	450.2 mm
Weight	13500 g
