Downloading and accessing HP Vision Diagnostics
Follow these steps to download the HP Vision Diagnostics utility from the HP Web site to a CD, DVD, or
USB flash drive. Then use the disk or drive to perform diagnostics on the workstation:
1. Go to
http://www.hp.com.
2. Select the Support & Drivers link.
3. Select the Download driver and software radio button.
4. Enter your product number in the text box, and then press Enter.
5. Select your operating system.
6. Select the Diagnostic link.
7. Locate HP Vision Diagnostics and select Download.
8. After the .iso file is downloaded, save the file to a USB flash drive (recommended for faster
performance) or use CD-ROM burning software to copy the .iso file to an optical medium.
9. Insert the disk or USB drive into the workstation while it is turned on.
10. Shut down the workstation.
11. Turn on the workstation. The system boots into HP Vision Diagnostics.
NOTE: If the system does not boot to the CD in the optical drive or the USB flash drive, you may
need to change the boot order. You may use the Computer Setup (F10) utility to change the boot
order, or press F9 to select the appropriate boot device.
12. At the boot menu, select either the HP Vision Diagnostics utility to test the various hardware
components in the computer or the HP Memory Test utility to test memory only.
NOTE: The HP Memory Test, a comprehensive memory diagnostic utility, runs as a stand-alone
application, outside of HP Vision Diagnostics.
If the workstation boots from a CD, you must use a separate boot CD to run the memory
diagnostic. Hence, HP recommends that you use a USB key to boot the diagnostic utilities. It is
faster than using a CD or DVD, and it accommodates both Memory and Vision diagnostics.
13. If you run HP Vision Diagnostics, select the appropriate language and click Continue.
14. In the End User License Agreement page, select Agree if you agree with the terms. The HP Vision
Diagnostics utility launches and displays the Survey tab.
186 Chapter 6 Diagnostics and troubleshooting ENWW

HP Z400 Specifications

General

Bus type	QPI
Processor cache	4 MB
Processor cores	2
Processor model	W3503
System bus rate	4.8 GT/s
Processor socket	-
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Number of processors installed	1
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	24 GB
Audio system	Realtek ALC262
Product type	Workstation
Motherboard chipset	Intel® X58 Express
Memory slots	6x DIMM
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1066 MHz
Memory layout (slots x size)	- GB
Graphics card	Quadro 600
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
HDD speed	- RPM
RAID levels	0, 1, 5, 10
HDD capacity	500 GB
HDD interface	SATA II
Storage media	HDD
Display included	No
USB 2.0 ports quantity	8
Parallel ports quantity	0
Chassis type	Minitower
Country of origin	China
Number of 5.25\" bays	3
Operating system installed	Windows 7 Professional
Operating system architecture	32-bit
Power supply	475 W
Processor ARK ID	40800
Processor package size	42.5 x 45 mm
Supported instruction sets	SSE4.2

Weight and Dimensions

Depth	455.3 mm
Width	167.9 mm
Height	450.2 mm
Weight	13500 g
