Sure Start has identied a problem (Manual Recovery Policy Set)
This computer has experienced a problem in locating a valid BIOS image, resulting in a failed startup. HP Sure
Start will normally repair this type of issue; however, on this computer HP Sure Start has been congured to
operate in manual mode key sequence. To proceed with the repair, press and hold the following keys: <ESC>
+<UP arrow>+<DOWN arrow>. To avoid the need for this manual recovery step, set the HP Sure Start recovery
policy to automatic. If this error reoccurs, a service event is required to identify the source of the error and
take appropriate corrective action.
NOTE: The computer will attempt to notify you of this problem through a series of blinking lights. When you
attempt to turn on the computer from an “O” or “Hibernated” state, lights associated with the caps lock and
num lock keys will both blink eight times followed by a pause, then continue in a repeating pattern.
POST Error Messages and User Actions
Test description Failure descriptions Error code Possible user actions
Product
information
Invalid value 00A Contact support for assistance.
Startup test Memory module 200 Attempt to reseat the memory module and then repeat the test.
See http://h20566.www2.hp.com/portal/site/hpsc/template.PAGE/
action.process/public/kb/docDisplay/?
javax.portlet.action=true&spf_p.tpst=kbDocDisplay&javax.portlet.begCac
heTok=com.vignette.cachetoken&spf_p.prp_kbDocDisplay=wsrp-
interactionState%3DdocId%253Demr_na-c01443371%257CdocLocale
%253Den_US%257CcalledBy
%253D&javax.portlet.endCacheTok=com.vignette.cachetokenfor details
on troubleshooting issues related to the memory module.
If the memory module still fails, contact support.
Startup test Hard Disk 1 SMART 301 Attempt to reseat the hard drive and repeat the test.
The hard disk drive may have failed. Contact support for assistance.
Startup test Hard Disk 2 SMART 302 The hard drive may have failed. Contact support for assistance.
Startup test Hard Disk 1 Quick 303 The hard drive may have failed. Contact support for assistance.
Startup test Hard Disk 2 Quick 304 The hard drive may have failed. Contact support for assistance.
Run-in test Memory module 200 Attempt to reseat the memory module and then repeat the test.
See http://h20566.www2.hp.com/portal/site/hpsc/template.PAGE/
action.process/public/kb/docDisplay/?
javax.portlet.action=true&spf_p.tpst=kbDocDisplay&javax.portlet.begCac
heTok=com.vignette.cachetoken&spf_p.prp_kbDocDisplay=wsrp-
interactionState%3DdocId%253Demr_na-c01443371%257CdocLocale
%253Den_US%257CcalledBy
%253D&javax.portlet.endCacheTok=com.vignette.cachetoken for details
on troubleshooting issues related to the memory module.
If the memory module still fails, contact support.
Run-in test Hard Disk 1 SMART 301 Attempt to reseat the hard drive and repeat the test.
The hard drive may have failed. Contact support for assistance.
Run-in test Hard Disk 2 SMART 302 The hard drive may have failed. Contact support for assistance.
Run-in test Hard Disk 1 Quick 303 The hard drive may have failed. Contact support for assistance.
Run-in test Hard Disk 2 Quick 304 The hard drive may have failed. Contact support for assistance.
Additional information 149

HP ZBook 15u G5 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Gray
Country of origin	China
Panel type	UWVA
Touchscreen	-
LED backlight	Yes
Display diagonal	15.6 \
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Total storage capacity	512 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Number of built-in speakers	2
HP segment	Business
HP speaker type	HP Dual Speakers
Front camera HD type	HD
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Pointing device	Touchpad
AC adapter power	- W
On-board graphics card ID	0x5917
On-board graphics card model	Intel® UHD Graphics 620
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Battery capacity	56 Wh
Number of battery cells	3
Bus type	OPI
Stepping	Y0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1356
Processor threads	8
Processor codename	Kaby Lake R
Configurable TDP-up	25 W
Processor frequency	1.9 GHz
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.2 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.1 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR3L8
Processor ARK ID	124968
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	251 mm
Width	370.8 mm
Height	18.6 mm
Weight	1770 g
