HP ZBook 15u G5 User Manual

Microsoft general troubleshooting of Windows bug check codes
●
If you recently added hardware to the system, try removing or replacing it. Or check with the
manufacturer to see if any patches are available.
●
Try running HP PC Hardware Diagnostics (UEFI).
●
Check with the manufacturer to see if an updated system BIOS or rmware is available.
●
Be sure that any expansion board is properly seated and all cables are completely connected.
●
Conrm that any new hardware that is installed is compatible with the installed version of Windows.
●
If new device drivers or system services have been added recently, try removing or updating them.
NOTE: Use safe mode when removing or disabling components. Safe mode loads only the minimum
required drivers and system services during the Windows startup. To enter safe mode, restart your
computer and press F8 at the menu that displays the operating system choices. At the resulting
Windows Advanced Options menu, choose Safe Mode.
●
Run a virus detection program. Viruses can infect all types of hard drives formatted for Windows, and
resulting drive corruption can generate system bug check codes. Be sure that the virus detection
program checks the Master Boot Record for infections.
●
Verify that the system has the latest service pack installed. To detect which service pack, if any, is
installed on your system, click Start, click Run, type winver, and then press Enter. The About Windows
dialog box displays the Windows version number and the version number of the service pack, if one has
been installed.
●
Disable BIOS memory options such as caching or shadowing.
●
Check the System Log and Application Log in Event Viewer to see if any additional error messages have
been logged recently. These might pinpoint the cause of the error.
Use Windows Debugging Tool
The https://msdn.microsoft.com/library/windows/hardware/551063%20(v=vs.85).aspx is one of the
primary tools used by Microsoft software developers to analyze and resolve errors that result in memory
dumps. Use the tool to determine the cause of the error. Follow general steps for downloading, setting up,
and using the Windows 10 debugging tool. A similar process is used for Windows 7 or Windows 8.
NOTE: The following screen shots provide only an example of the tool. Specics shown are not
representative of all applications of the debugging tool. This is a Microsoft tool supported by Microsoft.
Additional information 153

HP ZBook 15u G5 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Gray
Country of origin	China
Panel type	UWVA
Touchscreen	-
LED backlight	Yes
Display diagonal	15.6 \
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Total storage capacity	512 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Number of built-in speakers	2
HP segment	Business
HP speaker type	HP Dual Speakers
Front camera HD type	HD
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Pointing device	Touchpad
AC adapter power	- W
On-board graphics card ID	0x5917
On-board graphics card model	Intel® UHD Graphics 620
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Battery capacity	56 Wh
Number of battery cells	3
Bus type	OPI
Stepping	Y0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1356
Processor threads	8
Processor codename	Kaby Lake R
Configurable TDP-up	25 W
Processor frequency	1.9 GHz
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.2 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.1 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR3L8
Processor ARK ID	124968
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	251 mm
Width	370.8 mm
Height	18.6 mm
Weight	1770 g
