Interface Attributes
Table 5-66 Attributes of 1000BASE-T electrical interfaces
Item Description
Connector type RJ45
Interface attribute MDI/MDIX
NOTE
l The interfaces of most network cards are medium dependent interfaces
(MDIs).
l MDIX interfaces are usually used on hubs or LAN switches.
Standards
compliance
IEEE802.3, IEEE802.3u, IEEE802.3ab
Frame format Ethernet_II, Ethernet_SAP, or Ethernet_SNAP
Network layer
protocol
IP
Technical Specifications
Table 5-67 describes the technical specifications of the 4GEW-T interface card.
Table 5-67 Technical specifications of the 4GEW-T
Parameter
Description
Dimensions (W x
D x H)
201 mm x 223.5 mm x 19.82 mm
Maximum power
consumption
11 W
Weight 0.3 kg
5.5.11 4GEW-S (4-Port-GE Optical WAN Interface Card
The 4GEW-S interface card provides four GE optical interfaces.
4GEW-S stands for:
l 4: four interfaces
l GE: 1000M Ethernet
l W: WAN
l S: optical interface
Huawei AR1200&2200&3200 Series Enterprise Routers
Hardware Description 5 Cards
Issue 03 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
103
