5.1.3 Card Dimensions
This section explains the conventions for measuring cards and lists the dimensions of SIC, WSIC,
XSIC and EXSIC card.
Figure 5-5 illustrates the dimensions of a card.
Figure 5-5 Card dimensions description
Width
Depth
Height
NOTE
The card dimensions are defined as follows:
l Depth: the distance between the handle and the end of Printed Circuit Board (PCB)
l Width: the longest distance between the tops of two handles
l Height: the height of the ejector lever
Figure 5-6 shows the cards supported by the AR routers and Table 5-1 lists the card dimensions.
Figure 5-6 Card appearances
SIC
WSIC
XSIC
EXSIC
Huawei AR1200&2200&3200 Series Enterprise Routers
Hardware Description 5 Cards
Issue 03 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
55
