6.1 AC Power Cable
An AC power cable transmits AC power to the switch.
Application
An AC power cable connects the following:
l The AC input power jack on the chassis
l The other end is connected to the AC power supply
Appearance
Figure 6-1 shows the appearance of the AC power cable.
Figure 6-1 Appearance of the AC power cable
Specifications
NOTE
The AC power cables used in different countries and regions may have different specifications. The
following are the specifications of the international standard AC power cable.
Table 6-1 lists the specifications of the AC power cable.
Table 6-1 Specifications of the AC power cable
Item
Description
Cable type External power cable
Function 250 V AC/10 A complying with international standard
Huawei AR1200&2200&3200 Series Enterprise Routers
Hardware Description 6 Cables
Issue 03 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
131
