Table 5-90 Types and functions of interfaces on the 4G.SHDSL
Letter in
Figure
5-27
Name Qua
ntity
Description Cable Type
a G.SHDSL
(RJ45)
1 The 4G.SHDSL
provides one RJ45
interface, which
supports standard
network cables.
6.9 4G.SHDSL Cables or 6.5
Network Cable
Interface Attributes
Table 5-91 Attributes of G.SHDSL interfaces
Attribute Description
Connector type One RJ45 connector on one end and four RJ11 connectors on the other
end
Standards
compliance
G.SHDSL.bit
Transmission rate 5.696 Mbit/s per pair
Technical Specifications
Table 5-92 describes the technical specifications of the 4G.SHDSL.
Table 5-92 Technical specifications of the 4G.SHDSL
Item
Specification
Dimensions
(Depth x Width x
Height)
223.5 mm x 100.1 mm x 19.82 mm (8.8 in. x 3.94 in. x 0.78 in.)
Maximum power
consumption
8.2 W
Weight 0.35 kg (0.78 lb)
5.7.3 1PON (1-Port GPON/EPON Dual-Mode Interface Card)
The 1PON card is the EPON/GPON auto-sensing module on the AR routers.
