Table 6-17 Specifications of the synchronous/asynchronous serial interface cable
Item Description
Characteristic impedance 100 ohm
Cable type Twisted pair
Transmission rate
l V.24: 1200 bit/s to 64 kbit/s
l V.35/X.21/RS449/RS530: 1200 bit/s to 2.048 Mbit/
s
Color Dark blue (PANTONE 296U)
Diameter
l V.24 DTE/DCE cable, V.35 DTE/DCE cable, and X.
21 DTE cable: 0.38 mm (0.015 in.)
l RS449 DTE/DCE cable and RS530 DTE/DCE cable:
0.32 mm (0.013 in.)
Gauge 28 AWG
Pin
l V.24 DTE/DCE cable, V.35 DTE/DCE cable, X.21
DTE cable: 5 pairs + 8 pins
l RS449 DTE/DCE cable and RS530 DTE/DCE cable:
26 pins
6.9 4G.SHDSL Cables
This section describes the structure and technical specifications of the 4G.SHDSL cable.
Introduction
The connectors of a 4G.SHDSL cable are as follows:
l Four RJ11 connectors on the local end
l An RJ45 connector on the network side
Appearance and Structure
Figure 6-26 shows the appearance of the 4G.SHDSL cable.
Huawei AR1200&2200&3200 Series Enterprise Routers
Hardware Description 6 Cables
Issue 03 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
154
