Item Description
Data equipment type Data Circuit-terminating Equipment (DCE)
Table 5-8 Attributes of the MiniUSB-B interface
Item Description
Connector type MiniUSB-B, angle
Standards compliance USB1.0
Operating mode Device
Table 5-9 Attributes of the USB-A interface
Item Description
Connector type USB-A
Standards compliance USB2.0, compatible with USB1.0 and USB1.1
Operating mode Host
5.2.3 Technical Specifications
Table 5-10 describes the technical specifications of the SRU.
Table 5-10 Technical specifications of the SRU
Item
Specification
Dimensions
(depth x width x
height)
270.85 mm x 402.8 mm x 40.14 mm (10.67 in. x 15.83 in. x 1.58in.)
Maximum power
consumption
85.44 W
Weight 2.1 kg (4.63 lb)
5.3 WLAN Subcard
WLAN subcards are Wi-Fi modules.
5.3.1 Functions and Applications
Huawei AR1200&2200&3200 Series Enterprise Routers
Hardware Description 5 Cards
Issue 03 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
62
