Table 4-2 Technical specifications of the fan module
Item Specification
Dimensions (width
x depth x height)
27.4 mm x 478.6 mm x 84.3 mm (1.08 in. x 18.85 in. x 3.32 in.)
Weight 1.05 kg (2.32 lb)
Maximum power
consumption
60 W
Maximum wind
pressure
150 Pa
Maximum wind
rate
400 CFM
Maximum noise 61 dB
Operating voltage
of a fan
7 V DC to 15 V DC
4.3 AR3260 Fan Module
The fan module of the AR3260 is 3 U high. It is pluggable and uses front-access design.
Functions
The fan module is located on the right side of the AR3260 chassis for heat dissipation and
ventilation. If a single fan failed, the heat dissipation for the AR3260 will be affected. When this
occurs, replace the entire fan frame immediately.
Structure
The fan module of the AR3260 consists of a fan tray, three 12 V fans with dimensions 120 mm
(width) x 25 mm (depth), and a fan control board (FCB).
Panel
Figure 4-6 shows the panel of the fan module.
Huawei AR1200&2200&3200 Series Enterprise Routers
Hardware Description 4 Heat Dissipation System
Issue 03 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
48
