2.3.3 AR3200 Series
This section describes the structure of the AR3200.
Appearance
Figure 2-16 shows the front view of AR3260.
Figure 2-16 AR3260 front view
Figure 2-17 shows the rear view of AR3260.
Figure 2-17 AR3260 rear view
1: Pluggable card
2: ESD jack 3: Ground screw 4: AC jack
