Table 9-19 Attributes of G.SHDSL interfaces
Attribute Description
Connector type One RJ45 connector on one end and four RJ11 connectors on the other
end
Standards
compliance
G.SHDSL.bit
Transmission rate 5.696 Mbit/s per pair
9.10 Attributes of the Console Interface
This section describes the attributes of the console interface.
Table 9-20 lists the attributes of the console interface.
Table 9-20 Attributes of the console interface
Item Description
Connector type RJ45
Standards compliance RS232
Operating mode Full duplex Universal Asynchronous Receiver/
Transmitter (UART)
Data equipment type Data Circuit-terminating Equipment (DCE)
Table 9-21 lists the attributes of the MiniUSB-B interface.
Table 9-21 Attributes of the MiniUSB-B interface
Item
Description
Connector type MiniUSB-B, angle
Standards compliance USB1.0
Operating mode Device
9.11 Attributes of the USB Interface
This section describes the attributes of the USB interface.
Table 9-22 lists the attributes of the USB-A interface.
Huawei AR1200&2200&3200 Series Enterprise Routers
Hardware Description 9 List of Interface Attributes
Issue 03 (2012-04-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
209
