Huawei TaiShan 200 2280 User Manual

1 Physical Structure
The physical structure of the 2280 varies depending on the CPU conguration and
drive
conguration. This section uses the server with 12 drives as an example to
describe the physical structure of severs with dierent processors.
When congured with Kunpeng 920 7260, 5250, or 5230 processors, the server
provides 32 DIMM slots. Figure 1-1 shows the components of the server.
Figure 1-1 Components (server with Kunpeng 920 7260, 5250, or 5230
processors)
1
I/O module 1 2 I/O module 2
3 PSUs 4 Chassis
5 I/O module 3 6 Supercapacitor bracket
7 Air duct 8 Front drive backplane
9 Fan module brackets 10 Fan modules
TaiShan 200 Server
Maintenance and Service Guide (Model 2280) 1 Physical Structure
Issue 04 (2020-01-16) Copyright © Huawei Technologies Co., Ltd. 1

Huawei TaiShan 200 2280 Specifications

General

Brand	Huawei
Model	TaiShan 200 2280
Category	Server
Language	English
