Label Meaning Description
No stacking Do not stack after unpacking. This
may cause device damage.
No handling Do not carry the device using its
handle. This may cause injury or
damage.
Multiple inputs This label indicates that the device
has multiple power inputs.
Disconnect all power inputs before
you power o the device.
5.4 Basic Operations
5.4.1 Powering On the Server
Power on the server using one of the following methods based on the actual
situation:
● If the PSUs are properly installed but are not connected to an external power
supply:
Connect the external power supply to the PSUs. Then the server will power on
with the PSUs.
The default value of System State Upon Power Supply is Power on, which indicates
that the server automatically powers on after power is supplied to the PSUs. To
change the value of System State Upon Power Supply, log in to the iBMC WebUI and
choose Power > Power Control.
● If the PSUs are properly installed and connected to the external power supply
and the server is in the standby state (the power indicator is steady yellow),
power on the server as follows:
– Press the power button on the front panel to power on the server. For
details about the power button position, see 2.1 Front Panel
Components.
– Power on the server using the iBMC WebUI.
i. Log in to the iBMC WebUI. For details, see 8.2 Logging In to the
iBMC WebUI.
ii. Open the Power Control page.
○ For iBMC earlier than V500, choose Power > Power Control.
○ For iBMC V500 and later, choose System > Power > Power
Control.
iii. Click Power On. In the displayed dialog box, click Yes to power on
the server.
TaiShan 200 Server
Maintenance and Service Guide (Model 2280) 5 Removal and Installation
Issue 04 (2020-01-16) Copyright © Huawei Technologies Co., Ltd. 75
