6 CONTROLS
24
6.14 Idle speed adjusting screw
F03566-10
The idle speed is adjusted using the idle speed adjusting
screw
1
.
Increase the idle speed by turning the idle speed adjusting screw
clockwise.
Decrease the idle speed by turning the idle speed adjusting
screw counterclockwise.
The idle setting of the throttle valve body substantially influences
the vehicle’s starting behavior, a stable idle speed, and the vehi-
cle’s response when the throttle is opened.
An engine with a correctly set idle speed is easier to start than an
engine with the idle speed set incorrectly.
6.15 Shift lever
401950-10
Shift lever
1
is mounted on the left of the engine.
401950-11
The gear positions can be seen in the figure.
The neutral or idle position is between the first and second gears.
