CONTROLS 6
25
6.16 Foot brake lever
401956-10
Foot brake lever
1
is located in front of the right footrest.
The rear brake is engaged with the foot brake lever.
6.17 Side stand
401943-10
The side stand
1
is attached to the left side of the vehicle.
401944-10
The side stand is used for parking the motorcycle.
Info
When you are riding, side stand
1
must be folded up
and secured with rubber strap
2
.
6.18 Steering lock
S03571-10
Steering lock
1
is fitted on the left side of the steering head.
The steering lock is used to lock the steering. Steering, and
therefore riding, is no longer possible.
