CONTROLS AND EQUIPMENT
76
B710A01Y-EAT
(Not all models)
HEATING AND COOLING CONTROL
B710B01A-DAT
CENTRE VENTILATOR
The centre ventilators are located in the
middle of the dashboard.
To change the direction of the air flow,
turn the control knob on the middle of
the ventilator as desired.
1. Side Defrost Nozzle
2. Side Ventilator
3. Windshield Defrost Nozzle
4. Centre Ventilator
B710C01FC-EAT
SIDE VENTILATOR
The side ventilators are located on
each side of the dashboard. To change
the direction of the air flow, move the
knob in the centre of the vent. The
vents are opened when the vent knob is
moved to " " position. The vents are
closed when the vent knob is moved to
" ". Keep these vents clear of any
obstructions.
1. Side Ventilator
2. Side Defrost Nozzle
3. Centre Ventilator
4. Windscreen Defrost Nozzle
