CHECKING AND REPLACING
FUSES
SG200A1-E
Fusible Links
The fusible link prevents damage to
the wiring harness in the event of an
electrical system malfunction. Failure
of a fusiblelink is indicative of a seri-
ous overload condition having occurred
and therefore the electrical system
should be checked by a Hyundai
authorised repairer before a replace-
ment link is fitted.
WARNING:
Under no circumstances should a
fusible link be replaced with any-
thing other than a new link of the
same rating. The use of higher rated
links or other means of connecting
the circuit will create a potential fire
hazard.
GoodBad
G200A01FC
G190B01TB-GAT
Diesel Engine
At the scheduled maintenance inspec-
tion, belts should be examined for
cracks, wear, fraying or other evi-
dence of deterioration and replaced if
necessary.
Belt routing should also be checked to
be sure there is no interference be-
tween the belts and other parts of the
engine.
G190B01A
Power
steering
pump
A/C comp.
Auto tentioner fully
Alternator
