IN CASE OF EMERGENCY
2
IF THE ENGINE WILL NOT START
SD020B1-E
If the Engine Cannot be Cranked
1. If the vehicle is fitted with manual
transaxle, ensure that the clutch pedal is
depressed whilst cranking the engine. If
the vehicle is fitted with automatic
transaxle, ensure that the transaxle
selector is at the "P" or "N" position.
2. Check the battery terminals and con-
nections to ensure that these are
clean and also tight.
3. If the ignition warning lights dim when
the engine is cranked and the battery
terminals have been checked, a dis-
charged battery is indicated.
4. Do not attempt to push or tow start
the vehicle, refer to "Jump Starting"
for information regarding engine start-
ing when the battery is discharged.
D010C02A-EAT
If Engine Turns Over Normally
but Does Not Start
D010B01FC
1. Check fuel level.
2. With the key in the "OFF" position,
check all connectors at ignition coils
and spark plugs(For Petrol Engine)
or check all connectors at glow plug
and glow plug relay(For Diesel En-
gine). Reconnect any that may be
disconnected or loose.
3. Check fuel line in the engine com-
partment.
4. If engine still refuses to start, call a
Hyundai authorised repairer or seek
other qualified assistance.
SSA3020C
!
SD020A1-E
Seek assistance from the nearest
Hyundai authorised repairer with regard
to the method of ignition and fuel sys-
tem diagnosis.
CAUTION:
If the engine refuses to start, no
attempt should be made to push or
tow start the vehicle. Vehicles with
automatic transaxle or fuel injection
will not be able to be started in this
manner since no drive is transmitted
through the automatic transaxle
whilst the engine is not running, and
in the case of fuel injected deriva-
tives, the fuel pump will not operate
under tow start conditions. In addi-
tion, if the vehicle is equipped with
an exhaust catalyst, damage to the
catalyst may result if the vehicle is
tow started.
