274
Replacement Procedures and Illustrated Parts List
Item
No.
Part No.
(Order No.)
Description Notes
1 63H7518
63H7519
63H7520
Hammer Bank/Rbn Mask Cover
Hammer Bank/Rbn Mask Cover
Hammer Bank/Rbn Mask Cover
Models 004, 04P, 005, 05P
Models 008, 08P, 009, 09P
Models 012, 014
2 14H5274
24H8648
14H5516
24H9625
14H5517
90H3269
14H5275
14H5512
14H5513
Shuttle Frame Assembly
Shuttle Frame Assembly
Shuttle Frame Assembly
Shuttle Frame Assembly
Shuttle Frame Assembly
Shuttle Frame Assembly
Hammer Spring Assemblies:
Hammer Spring Assembly
Hammer Spring Assembly
Hammer Spring Assembly
Models 004, 04P
Models 005, 05P
Models 008, 08P
Models 009, 09P
Model 012
Model 014
Models 004, 04P, 005, 05P
Models 008, 08P, 009, 09P
Models 012, 014
3 14H5644
90H3268
Power Supply PCBA
Power Supply PCBA
Models 004, 04P, 005, 05P
, 008,
08P
, 012
Models 009, 09P
, 014
4 Ref P101 Cable Connector
5 Ref Cable Assy, AC In, Power Supply Part of Field Kit, AC Assy
14H5289
6 14H5643
24H8647
90H3271
Controller Board, CMX, V5.0
Controller Board, CMX, V5.5, 25 MHz
Controller Board, CMX, V5.5, 40 MHz
All models 004 and 04P. Models
008 and 012 with Ser. Nos.
01AXXXX, 01BXXXX and
01CXXXX
All models 005, 05P, and 08P.
Models 008 and 012 with Ser.
Nos.01DXXXX, 01EXXX, and
higher. All models 009, 09P.
Model 014, 050, P50, 010, P10,
015
7 Ref Motor Sensor, Left, Cable Assy Housing Connector Kit 14H5288
8 Ref Hammer Bank Logic Cable Assy
9 Ref Shuttle Motor Cable Assy
10 Ref Hammer Bank Power Cable Assy
11 Ref Motor Sensor, Right, Cable Assy Housing Connector Kit 14H5288
12 14H5287
14H5522
Centronics I/O Cable Assy
Centronics/Dataproducts Adapter Optional cable assembly
13 Ref Control Panel Cable Assy
14 14H5211 Clamp, Shaft, Receiving
15 Ref Screw, Captive, Power Supply (3)
16 Ref SIMM, Flash Memory See also page 224
17 Ref SIMM, DRAM See also page 224
18 14H5282 Switch Assembly, Cover Open
To Next Page
