379Power Stacker
5. Remove the paper deflector. (See Figure 59.)
Paper Deflector
Figure 59. Removing the Paper Deflector
6. Remove three screws and washers from the stacker control panel. (See
Figure 60.)
Washer
Long Screw
Short Screw (2)
Washer (2)
Figure 60. Removing the Stacker Control Panel
