Specifications
The uninterruptible power supply includes the following specifications.
Table 1. UPS3000 LV and UPS3000 HV specifications
UPS3000 LV UPS3000 HV
Height 89 mm (3.5 in.) 89 mm (3.5 in.)
Width 482.6 mm (19.0 in.) 482.6 mm (19.0 in.)
Depth 622.3 mm (24.5 in.) 622.3 mm (24.5 in.)
Additional clearance 25 mm (0.98 in.) for circuit
breakers
3 mm (0.12 in.) for outlets
25 mm (0.98 in.) for circuit
breakers
3 mm (0.12 in.) for outlets
Weight 37.0 kg (82.0 lb) 37.0 kg (82.0 lb)
Operating temperature at
0 to 3000 m (0 to 10,000 ft)
0°to 40°C (32° to 104°F) 0°to 40°C (32° to 104°F)
Maximum operating
altitude
2000 m (6562 ft) 2000 m (6562 ft)
Relative humidity 0 to 95% noncondensing 0 to 95% noncondensing
Nominal input voltage 120 V 220 V ac (selectable from
200-240 V ac))
Maximum input current 30 amps 16 amps
Input voltage range for
main operations
90 to 144 V 160 to 288 V
Input voltage adjustable
range for main operations
77 to 152 V 154 to 288 V
Nominal output voltage 120 V 220 V, configurable for 200,
220, 230, or 240 V
Input frequency 50/60 Hz +/-4 Hz (auto sensing) 50/60 Hz +/-4 Hz (auto
sensing)
Rated power output 2880 VA 3000 VA
Output power capacity in
watts
2700 W 2700 W
Circuit breakers Three supplemental circuit
breakers rated at 15 amps, one
for each load segment
Three supplemental circuit
breakers rated at 15 amps,
one for each load segment
Fixed power cord Length: 12 ft; Nema L5-30P
connection to source
Input connection type IEC-320 C20, connection to
source using country
specific line cords
Power outlets One L5-30R outlet
Six 5-15R outlets
Six IEC C13 outlets
One IEC C19 outlet
Audible noise at 1 meter <45 dBA normal
<50 dBA Battery mode
<45 dBA normal
<50 dBA Battery mode
Online thermal dissipation 171 Btu per hour 171 Btu per hour
Chapter 1. Introduction 3
