7. Select Date and Time from the menu at the top of the page and enter the
applicable date and time information in the specified format.
8. Select Set Values to save the date and time settings.
The Web/SNMP Card is now configured for operation on your network. See the
online help for detailed information about each menu selection.
Using the Web/SNMP card in serial pass-through mode
During normal operation, the Web/SNMP card controls the communication path to
the uninterruptible power supply and provides network-based access to
uninterruptible power supply data through the Web and through SNMP. You can
disable the normal operation of the Web/SNMP card and enable serial
communication in a pass-through mode directly to the uninterruptible power supply.
You can use serial pass-through mode for scenarios similar to the following:
v The uninterruptible power supply firmware requires a field upgrade and a 9600
baud serial port connection to the uninterruptible power supply is required to
perform the upgrade.
v You want to run a local copy of the Powerware LanSafe software and
communicate serially with the uninterruptible power supply.
Before
you begin, go to http://www.powerware.com/ to download a later version of
the Web/SNMP card firmware, if available.
To set up the serial pass-through mode, complete the following steps:
1. Change the dip switch positions on the Web/SNMP card to On and On. The
default is Off and Off. For the location of the dip switch, see the illustration on
page 27.
2. Press the Web/SNMP card Reset switch to restart the card in the serial
pass-through mode.
3. Using the DB9-to-RJ-45 cable that comes with the uninterruptible power supply,
connect the RJ-45 end of the cable into the COM connector on the Web/SNMP
card.
4. Connect the DB9 end of the cable into an available serial port on a workstation
or notebook computer.
5. You can now run applicable software on your workstation or notebook computer
and can communicate serially with the uninterruptible power supply at 9600
baud, 8 bits, not parity, and 1 stop bit.
Note: In serial pass-through mode, communication through the Web/SNMP
Ethernet connector stops and any existing connections, for example, to
NetWatch software clients or SNMP management tools, also stops.
6. When you are finished using the Web/SNMP card in serial pass-through mode,
disconnect the DB9-to-RJ-45 cable from the card and the workstation or
notebook computer.
7. Return the dip switch to the original settings.
8. Press the Reset button to restart the card.
Chapter 4. Using the Web/SNMP card 33
