Virtual media
key connector
Virtual media
key (front)
Mounting bracket
(rear)
Mounting tab
4. Align the virtual media key with the mounting tab and slide it down the tab onto
the connector on the system board. Press the virtual media key down into the
connector until it is firmly seated on the system board.
5. Install and lock the side cover (see “Installing the side cover” on page 146).
6. Reconnect the power cord and any cables that you removed.
7. Turn on the peripheral devices and the server.
Removing the system battery
The following notes describe information that you must consider when you replace
the battery:
v IBM has designed this product with your safety in mind. The lithium battery must
be handled correctly to avoid possible danger. If you replace the battery, you
must adhere to the following instructions.
Note: In the U. S., call 1-800-IBM-4333 for information about battery disposal.
v If you replace the original lithium battery with a heavy-metal battery or a battery
with heavy-metal components, be aware of the following environmental
consideration. Batteries and accumulators that contain heavy metals must not be
disposed of with normal domestic waste. They will be taken back free of charge
by the manufacturer, distributor, or representative, to be recycled or disposed of
in a proper manner.
v To order replacement batteries, call 1-800-IBM-SERV within the United States,
and 1-800-465-7999 or 1-800-465-6666 within Canada. Outside the U.S. and
Canada, call your support center or business partner.
Chapter 5. Removing and replacing server components 183
