BASIC OPERATION
Turning power ON ■
Hold down q for 2 seconds to turn ON the power.
If the transceiver is programmed with a start-up password, w
this needs to be entered before the transceiver can be op-
erated.
• The keys in the table below can be used for password input:
• The transceiver detects numbers in the same block, as identical.
Therefore “01234” and “56789” are the same.
KEY
NUMBER
0
5
4
9
3
8
2
7
1
6
MONI
F
SET
TSQL
PRIO
LOW
SCAN
O࡮G࡮P
CH
SET࡮P
RS
TAG
SQL
[PWR]
O࡮G࡮P
RS
SCAN
TAG
PRIO
SET࡮P
LOW
O࡮G࡮P
RS
SCAN
TAG
PRIO
SET࡮P
LOW
e When the “PASWD” indication does not clear after input-
ting 4 digits, the input number may be incorrect. Turn OFF
the power and start over from step q.
If the input number is not as you disired, also start over
from step q.
Volume ■
➥ Push or to select the desired volume level.
• “ ” appears when volume level 0 is selected (while the internal
speaker is muted).
Channel ■
➥ Push
CH
SQL
to enter the channel selection mode, then push
or to select the desired channel.
• Holding down or , the displayed channel changes con-
tinuously until channel 1 is selected.
• When channel 1 is selected, beeps sound.
• ‘CB-XX’ appears when the CB channel is selected, and ‘RPT-XX’
appears when the RX channel is selected.
• “ ” appears when you select the channel selection mode.
Appears
