3
1
ACCESSORIES AND INSTALLATION
1
Release lever
NOTE
• When detaching the transceiver from the mounting brack-
et, push up and hold the release lever, then pull the trans-
ceiver to the direction of the arrow.
• The mounting bracket can be attached even upside down.
When detaching the transceiver from the bracket in this
case, hold down the release lever, then pull the transceiv-
er to the front.
Microphone D
Connect the supplied microphone as illustrated below.
Microphone hanger D
Attach the supplied microphone hanger (with the microphone
hanger attachment plate) as illustrated below.
HM-182
Microphone hanger
Microphone hanger
attachment plate
Put double-faced tape* on the
back side of the attachment plate.
*Not supplied.
Microphone hanger
without attachment plate
To Next Page
