28
6
SCAN
Scan types ■
The transceiver has 4 scan types, Tag function and 4 Re-
sume options, for scanning versatility.
Repeatedly scans all Tag channels in sequence.
ch 40
ch 1 ch 2 ch 3
ch 4
ch 5
ch 6ch 39
OPEN SCAN
Repeatedly watches a designated Priority chan-
nel after scanning 5 tagged channels.
Priority
channel
GROUP OR PRIORITY SCAN
ch 1
ch 2 ch 3 ch 4
ch 5
ch 10
ch 9 ch 8 ch 7
ch 6
Tag channels are independently set for Open, Group and Pri
ority scans. Initially, all channels may be set as tag channels
for all scans.
RPT-02
RPT-02RPT-01
Scan cancel
RPT-48
RPT-01
RPT-03RPT-04
RPT-48
REPEATER SEARCH SCAN
Scans all Repeater channels (‘RPT-01’ to ‘RPT-08’ and
‘RPT-41’ to ‘RPT-48’)* in sequence. If there are no busy
channels after scanning channels ‘RPT-01’ to ‘RPT-08’
and ‘RPT-41’ to ‘RPT-48,’* it begins scanning from
‘RPT-01’ again, then the transceiver transmits a signal to
search for a repeater while scanning.
* Excludes Emergency Repeater ‘RPT-05.’
