104
OTHER FUNCTIONS
12
■ Programming a DTMF code
DTMF codes are used for autopatching, accessing repeaters,
controlling other equipment, etc. The transceiver has 10
DTMF memory channels (Ch01–Ch10) for storage of often-
used DTMF codes of up to 16 digits.
q Push and hold [./EMR/DTMF.M](#) for 1 sec. to enter
DTMF memory.
w Rotate [DIAL]
†
to select the desired DTMF memory chan-
nel.
•“T-CALL” appears when a 1750 Hz tone burst signal is selected.
(p. ??)
e Push and hold [6/M.N](
≈≈
) for 1 sec. to enter programming
mode.
• Previously programmed DTMF code is cleared.
r Push the desired keys to input the characters.
• [VFO/MHz](A) inputs “A,” [MR/S.MW](B) inputs “B,”
[CALL/RX➝CS](C) inputs “C,” [BAND](D) inputs “D,”
[./EMR/DTMF.M](#) inputs “#” and [REC/MODE](✱) inputs “✱”.
• Up to 16 digits can be programmed.
• Push [MAIN/DUAL] to delete the cursor placed code.
• Push and hold [MAIN/DUAL] for 1 sec. to delete the cursor
placed or later codes.
t Repeat step r until the desired code is input.
y Push [MENU/LOCK] to program the DTMF code and exit
programming mode.
• Entering 16th digit automatically exits the programming mode.
