Icom IC-91AD User Manual

106
12 OTHER FUNCTIONS
■ Clearing a DTMF memory
An unwanted DTMF memory can be cleared (erased).
q Push and hold [./EMR/DTMF.M](#) for 1 sec. to enter
DTMF memory mode.
w Rotate [DIAL]
†
to select the desired DTMF memory chan-
nel to be cleared.
e Push [6/M.N](
≈≈
) to enter programming mode, and rotate
[DIAL] to set cursor to 1st digit.
r Push and hold [MAIN/DUAL] for 1 sec. to clear the se-
lected DTMF memory channel.
• The DTMF memory channel is cleared.
t Push [MENU/LOCK] to exit programming mode.
■ Confirming a DTMF memory
The DTMF memory can be confirmed with a DTMF tone.
q Push and hold [./EMR/DTMF.M](#) for 1 sec. to enter
DTMF memory mode.
w Rotate [DIAL]
†
to select the desired DTMF memory chan-
nel.
e Push [SQL] to confirm the DTMF memory contents.
Push [SQL], then sounds DTMF
codes.
Ch01
6
1234567
89AB
SQL:BACK MAIN:CLR
DTMF MEMORY
Ch01
6
SQL:BACK MAIN:CLR
DTMF MEMORY
[DIAL]
Ch01Ch01
01234567 01234567
89ABC*#0 89ABC*#0
:SET
:BACK
:SEL
:EDIT
DTMF MEMORY
r
[DIAL]
•
•
The cursor is blinking.
The cursor is blinking.
When entering DTMF programming
mode.
After clearing the DTMF memory.
Ch01Ch01
6
12345671234567
89AB 89AB
SQL:BACKSQL:BACK MAIN:CLRMAIN:CLR
DTMF MEMORY
r
Ch01Ch01
6
SQL:BACKSQL:BACK MAIN:CLRMAIN:CLR
DTMF MEMORY
r
Ch01
01234567
89ABC*#0
:SET
:BACK
:SEL
:EDIT
DTMF MEMORY
