111
12
OTHER FUNCTIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
■ Tone/DTCS squelch
q Set the desired operating frequency, CTCSS tone and
DTCS code.
w Push and hold [7/DSQ/TONE] for 1 sec. several times to
activate the tone or DTCS squelch. (TONE, TSQL or
DTCS)
• Subaudible tone encoder “TONE,” tone squelch “TSQL,” pocket
beep “TSQLS,” DTCS squelch “DTCS,” DTCS beep
“DTCSS” and no tone operation are activated in order.
• Rotating [DIAL] while pushing [7/DSQ/TONE] also selects the
tone functions.
e Operate the transceiver in the normal way.
r When the received signal includes a matching tone/code,
the squelch opens and the signal can be heard.
• When the received signal’s tone/code does not match,
tone/DTCS squelch does not open, however, the S-indicator
shows signal strength.
• To open the squelch manually, push and hold [SQL].
■ Digital code/digital call sign
squelch
q Set the desired operating frequency on DV mode, Digital
code and my call sign.
w Push and hold [7/DSQ/TONE] for 1 sec. several times to
activate the digital code or digita call signl squelch. (DSQL
or CSQL)
• Digital call sign squelch “DSQL,” Digital call sign beep
“DSQLS”, Digital code squelch “CSQL,” Digital code beep
“CSQLS” and no tone operation are activated in order.
• Rotating [DIAL] while pushing [7/DSQ/TONE] also selects the
tone functions.
e Operate the transceiver in the normal way.
r When the received signal includes a matching call
sign/code, the squelch opens and the signal can be heard.
• When the received signal’s call sign/code does not match, digital
call sign/digital code squelch does not open, however, the S-in-
dicator shows signal strength.
• To open the squelch manually, push and hold [SQL].
