Inovance MD310 T2.2B User Manual

1 Product Information
- 3 -
1� Product Information
1�1 Designation
MD310 series AC drive
MD310
X
Voltage Class
T
X.X X
Mark
B
Mark
Yes
Three-phase 380 V
Built-in Braking Unit
Null
No
Applicable motor, (kW)
Mark
0.4
0.4
0.7
0.75
0.4
0.4
18.5
18.5
1�2 Nameplate
MODEL: MD310T0�7B
INPUT: 3PH 380-440 VAC, 3�4 A, 50/60 Hz
OUTPUT:
3
PH 0-440
VAC, 2�
1 A, 0-500
Hz, 0�75 kW
Suzhou Inovance Technology Co�,Ltd�
S/N: 013010124D900004
Nameplate
AC drive model
Rated input
Rated output
Manufacturer
Barcode
S/N code

Inovance MD310 T2.2B Specifications

General

Rated Power	2.2 kW
Control Mode	V/F control, Sensorless vector control (SVC)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short circuit
Communication Interface	Modbus RTU
Humidity	5% to 95% (non-condensing)
Altitude	Below 1000m (derating above 1000m)
Operating Temperature	-10°C to +40°C (derating above 40°C)
