v60E - Maritime VSAT Antenna System

7.4 Starting Install Wizard

The Install Wizard will give you a guide by going through the steps of setup for the antenna system

commissioning. We highly recommend using this wizard to complete the installation and commissioning

of the system. You can exit the wizard at any time by clicking the Finish button. You can also skip steps

by clicking the Next button. Before you start, make sure the basic devices (antenna, modem, etc) are

connected to the ACU properly. After accessing the AptusNX main page, go to the INSTALL WIZ. on the

main menu then follow these steps.

Welcome Page

Welcome message is displayed. Click

the Next button to start.

NOTE

Refer to the "Chapter 9. Using AptusNX" on page 53 for detailed description of each function.

Step 1: GPS

Set the GPS position of the vessel for

the satellite searching. Check the GPS

status connected to the antenna system.

The colored indicator next to the title

shows the GPS status. Make sure the

GPS indicator is Blue (blinking).

• Blue (blinking): The system received a

correct GPS signal.

• Red: The GPS signal is abnormal, or

the received value is incorrect (Error).

• Black: The system has not received

any GPS signal. You can enter the GPS

value manually to set the GPS position.

Click the Next button to go to the next

step.
