Specification
10.2 Environmental Specication
Antenna Control Unit (ACU)
ACU Size 431 mm x 350 mm x 44.3 mm
ACU Weight 5.2 Kg
LED Indicator
Six LEDs for POWER, INT/SEARCH, TRACKING, LOCK,
SETUP/TEST, ERROR
Ship's Gyrocompass Interface NMEA 0183
PC Interface
Front: Ethernet port, USB (PC, DN: Not working)
Back: RS-232C (57600 bps 8, N, 1)
Modem Interface Ethernet port, RS-232/422, I/O Console
Ethernet port
Front: RJ-45 Management LAN port (1 ea)
Back: RJ-45 LAN port (1 ea)
RF Port
Antenna: N-Type (1 ea)
Modem Tx/Rx: F-Type (2 ea)
Input Power 100 ~ 240 V AC, 50/60 Hz, 1A
Test Intellian Standard
Temperature
(ADE)
Operational -25 °C to +55 °C (IEC-60945)
Survival -40 °C to +80 °C (IEC-60945)
Storage -40 °C to +85 °C (IEC-60945)
Temperature
(ACU)
Operational -15 °C to +55 °C (IEC-60945)
Survival -25 °C to +70 °C (IEC-60945)
Storage -40 °C to +85 °C (IEC-60945)
Vibration
Operational IEC-60945
Survival IEC-60721-3-6 Class 6M3
Shock
Operational IEC-60068-2-27 Method Ea 20g, 7 ms
Survival (Transient) IEC-60721-3-6 Class 6M3 type II 30g, 6 ms
Survival (Bump) IEC-60068-2-29 Method Eb 25g, 6 ms
Salt Mist
Saline solution: 5 ±1 % NaCl
Storage period: 7 Days (IEC-60945)
Water Proong IPX6 (IEC-60529)
