86
v60E - Maritime VSAT Antenna System
Antenna System
Antenna Radome Height 935 mm (36.81")
Antenna Radome Diameter Ø860 mm (33.85")
Antenna Reector Diameter Ø650 mm (25.59")
Antenna Unit Weight (With Radome) <42 kg (92.59 Ibs)
Platform 3-axis: Azimuth, Elevation, Cross-level
Positioning
3-axis Velocity Mode Servo Control:
Azimuth, Elevation, Cross-Level
Pedestal Motion
Range
Azimuth Range Unlimited
Elevation Range -20° to +115°
Cross-level Range Up to ±37º
Pointing Stabilization Accuracy 0.2° max in presence of specied ship motions
Ship's motion
Roll ±25° at 6 second
Pitch ±15° at 6 second
Yaw ±8° at 6 second
Turning rate 10°/sec
AZ/EL/CL motor BLDC Motor
Motor Brake Without motor brake
Sensor 3 axis Gyro-Rate Sensor & 2 axis Tilt Sensor (Fixed Sensor)
Rx
Frequency 10.7 ~ 12.75 GHz Ku-band
Gain Min. 36.3 dBi @ 11.7 GHz (without radome)
G/T over Rx Range Min. 15.4 dB/K @ 12.75 GHz (30˚ EL, with Radome)
Tx
Frequency 13.75 ~ 14.5 GHz Ku-band
Gain Min. 37.7 dBi @ 14.25 GHz (without Radome)
EIRP Min. 44.5 dBW @ 14.25 GHz (6 W BUC, with Radome)
Cross Pol isolation 30 dBc
Tx to Rx Isolation 80dBc @ 13.75~14.5GHz
Polarization Cross-Pol Only
BUC NJRC 6W Ku-band BUC (Model no. NJT8376UN, N type)
LNB
Universal VSAT PLL LNB
(Low band: 9.75 GHz, High band: 10.6 GHz)
ACU to ADU Cable (Antenna Cable)
Single 50 coax RF cable connected from ACU to ADU for Rx,
Tx, FSK, Reference and Power
Input power 48 V DC (max 300 W) through a single RF cable
Chapter 10. Specification
10.1 Technical Specication
