20 xGen Installation & Programming Guide
Onboard outputs 5 - BELL, strobe, siren and power outputs
Maximum output number 256
Maximum action number 256, main panel supports 32 actions,
each output module adds 32 actions, 7 output
modules will provide a maximum of 256 actions
Partitions:
NXG-64(IP) 96
NXG-256IP 32
NXG-512IP 96
Maximum keypad 16
Maximum expander 32 (including keypads)
Maximum user number:
NXG-64(IP) 100
NXG-256IP 256
NXG-512IP 256
User Permissions 128
Non-volatile Memory
Event log capacity 1024
Data retention (log, program settings) 10 years
Ethernet connection (IP only)
Supported standard IEEE 802.3u
Speed 10BASE-T or 100BASE-TX
Duplex Half-duplex and full-duplex
Cabling FTP (foiled twisted pair) Cat 5e cable or better
xGen bus
Type 4 wire RS485 bus
High common mode tolerance (25V)
Capacity Up to 32 devices
Range 800m
Recommended Cable Belden 8723 2 pair twisted shielded data cable
or exact equivalent
Current Consumption
Product Main description
Current Consumption
(non-alarm)
Current
Consumption (alarm)
NXG-64 64 zone panel no IP 100mA typical 100mA typical
NXG-64IP 64 zone panel /w IP 100mA typical 100mA typical
NXG-256IP 256 zone panel /w IP 100mA typical 100mA typical
NXG-256IP-M 256 zone panel /w IP 100mA typical 100mA typical
NXG-512IP-M 512 zone panel /w IP 100mA typical 100mA typical
NXG-1820-EUR Touchscreen keypad 100mA typical 175mA max
NXG-208 8 zone expander 25mA 25mA
NXG-220 20 zone expander 30mA 30mA
NXG-504 4 relay output expander
20mA idle
70mA 4 relays on
20mA idle
70mA 4 relays on
NXG-510 10 relay output expander
20mA idle
160mA 10 relays on
20mA idle
160mA 10 relays on
