xGen Installation & Programming Guide 21
Output Current Rating
Output Max Current Rating
Combined J10 POS, J7 Output 2+, J7 Output 1+ 1A max at 13.8VDC
J4 POS 1A max at 13.8VDC
Combined J11 POS, J15 POS, J17 POS, J19 POS 1A max at 13.8VDC
Auxiliary current and battery capacity
Discharge
Time
Charge
Time
7.2Ah Battery
(BS127N)
12Ah Battery
(BS130N)
18Ah Battery
(BS131N)
Reference
12 72 500 900 -
EN 50131 Grade
1 and 2
12 24 200 900 - INCERT
12 72 - - 1000
Not tested by
ANPI
12 24 - - n/a
Not tested by
ANPI
Example for NXG-64 EN Grade 2
When using battery backup as specified for EN Grade 2 using a 7.2Ah battery,
the maximum available auxiliary current is 500 mA.
Environmental
Operating temperature −10 to +55°C
Humidity 95% noncondensing
IP protection grade IP30
Colour White
EN 50131 grade and class Grade 2, Class II
NXG-1820E ACE classification Type A
Physical Dimensions and Weight
Product Main description Dimensions (LxWxH mm) Weight (g)
NXG-64 64 zone panel no IP 371 x 371 x 118 mm 2830 g
NXG-64IP 64 zone panel /w IP 371 x 371 x 118 mm 2830 g
NXG-256IP 256 zone panel /w IP 371 x 371 x 118 mm 2830 g
NXG-001 Plastic Enclosure 371 x 371 x 118 mm 1830 g
NXG-003 Metal Enclosure 475 x 395 x 130 mm 7150 g
NXG-1820-EUR Touchscreen keypad 18 x 82 x 125 mm 150 g
NXG-208 8 zone expander 135 x 80 x 55 mm 150 g
