Load Function
Edit Edit list program.
CC / CV
/ CW /
CR
Set the operation mode for list program: CC, CV,
CW or CR.
Step
Count
The total number of steps included in the List
program.
Step 1
Value
Parameter value for Step1. The current appears
when CC mode is selected; the voltage appears
when CV mode is selected. The resistance ap-
pears when CR mode is selected; the power ap-
pears when CW mode is selected.
Step 1
Slope
Slope value setting for Step1.
Step 1
Width
Dwell time setting for Step1. The range is from
0.001 to 86400 seconds.
Repeat Set the number of list file repetitions.
End
State
Set the running state after the list program is run-
ning over.
Last After the List program finishes run-
ning, the input is kept as the setting
in the last step, and the working
mode remains as the setting in the
List file.
Normal After the List program finishes run-
ning, the working mode and input
return to the settings before the
List running.
Trig Out Function switch that triggers the signal output. It
is applicable to the scenario of synchronously
controlling multiple units, that is, by connecting
the outer loop interfaces TX and RX of the fiber to
realize List synchronization triggering between
multiple units.
None Turn off (default)
Tout Turn on
Save to
group
Save the edited List program.
Copyright © Itech Electronic Co., Ltd.
54
