Maintenance Guide
1-10
1-2. Replacing the Pulleys
1-2-1. Replacing the Pulley XA
Carry out the replacement work in the same manner as for the timing belt XM in 1-1-1.
1-2-2. Replacing the Pulley XM (X-Motor Assembly)
Carry out the replacement work in the same manner as for the timing belt XM in 1-1-1.
1-2-3. Replacing the Pulley YA
Carry out the replacement work in the same manner as for the timing belt YM in 1-1-3.
1-2-4. Replacing the Pulley YM (Y-Motor Assembly)
Carry out the replacement work in the same manner as for the timing belt YM in 1-1-3.
1-2-5. Replacing the Pulley YB
Carry out the replacement work in the same manner as for the timing belt YB in 1-1-4.
