– 97 –
Name of part
Eyelet buttonhole presser
holding plate, left
Eyelet buttonhole presser
holding plate, right
Eyelet buttonhole presser
holding plate, left
Eyelet buttonhole presser
holding plate, right
Shape of hole Eyelet buttonhole Eyelet buttonhole
Stitch length 10 to 34 10 to 38
Shape
Part No.
40115322 40115323 32027104 32027005
Type For J01 and C01 types For J00 and C00 types
11-3. Presser holding plate
X
Y
Name of part For eyelet buttonhole For decorative buttonhole
Shape
Part No. X Y L Remarks
Eyelet
buttonhole
Provided as standard 40115664 2.8 4.3 26
Only for the sewing machine provided
with the needle thread trimmer
40115665 2.8 4.3 38
32063604 2.9 4.4 24
Optional
spacer is
used *1
32063703 2.9 4.4 32
Only for the sewing machine provided
with the needle thread trimmer
32063802 2.1 3.2 38
32063901 2.1 3.2 24
32064008 2.1 3.2 32
32064107 3.2 5.4 38
32064206 3.2 5.4 24
32064305 3.2 5.4 32
Only for the sewing machine provided
with the needle thread trimmer
32066904 2.7 5.1 38
Decorative
buttonhole
14041404 0 0 38
32065302 0 0 24
32065401 0 0 32
*1 Part number of the optional spacer is 40115728.
Adhere the optional spacer and the cloth trimming knife
with each other with their holes aligned so as to prevent
the holes are covered.
L
11-4. Cloth cutting knife
Optional spacer
Holes are
aligned
Cloth trimming knife
