− 60 −
7-24. Setting the number of stitches of slant section of taper bar
Number of stitches of the slant section from the taper bar
to the parallel section can be set.
Set the knife number by means of –/BACKWARD key
❻ or +/FORWARD key ❼.
The number of stitches can be set in the range from
two to (the number of stitches of taper bar).
7-25. Compensation of the number of stitches of the right side taper bar
Number of stitches of the right side taper bar can be
decreased and the overlapping section can be made
less.
Set the knife number by means of –/BACKWARD key
❻ or +/FORWARD key ❼.
The number of stitches can be set in the range from –
(the number of stitches of taper bar) to 0 (zero).
7-26. Setting the straight bar length
❼
❻
❼
❻
❼
❻
Number of stitches
Length
Number of stitches
In this step of procedure, the length of straight bar is
to be set.
Set the knife number by means of –/BACKWARD key
❻ or +/FORWARD key ❼.
The straight bar length can be set in increments of 0.1
mm in the range from 2.0 to 10.0 mm.
The straight bar length should be set so that
the throat plate and the eyelet presser sup-
port plate do not interfere with each other, in
consideration of the position of the presser
plate when the cloth opening mechanism is
opened.
