1. SPECIFICATIONS
Specications J type C type
1 Application Jeans Cotton pants, working pants
2
Operating temperature
range
5°C to 35°C
3 Operating humidity range 35 % to 85 % (with no condensation)
4
Number of patterns that
can be stored in memory
99 (1 to 99) (standard patterns have been factory-numbered 90 to 99)
5 Input power
Single-/3-phase 200 to 240 V 50/60 Hz
Supply voltage uctuation: Rating ± 10 %
6
Sewing speed
400 to 2,500 sti/min (in 100 sti/min steps)
7 Thread trimmer type
Needle thread
trimmer type (00)
Overall thread
trimmer type (01)
Needle thread
trimmer type (00)
Overall thread
trimmer type (01)
8 Sewing length 10 to 38 mm 10 to 34 mm 10 to 38 mm 10 to 34 mm
9 Buttonhole length 10 to 38 mm
*1
10 to 28 mm 10 to 38 mm
*1
10 to 28 mm
10 Needle throwing width
2.0 to 4.0 mm (factory-setting at the time of delivery: 2.5 mm)
[1.5 to 5.0 mm by compensation on the feed panel]
11
Length of buttonhole with
taper bar
3 to 15 mm *2
12 Lift of presser foot Standard 13 mm
13 Change of stitch shape Selection by program
14 Buttonhole cutting Cut-before knife + Cut-after knife, without knife
15
Cloth cutting knife drive
method
Driven by air cylinder
16 Feed method Intermittent feed by stepping motor
17 Needle used DO x 558 Nm90 to 120 (Needle count attached at the time of delivery: Nm110)
18 Safety device Pause switch & automatic stop function at the time of detection of a trouble
19 Lubricating oil JUKI MACHINE Oil No. 18
20 Air pressure
Main regulator: 0.5 MPa
Hammer pressure regulator: Standard 0.35 MPa (max. 0.4 MPa)
21 Air consumption
49.5 ℓ /min (11.6 cycles/min)
22 Machine dimensions
Machine head: 382 mm (width) x 656 mm (length) x 584 mm (height)
Complete unit (Table-xed type)
: 1050 mm (width) x 700 mm (length) x 1248 mm (height) *3 (excluding the thread stand)
Complete unit (Semi-sunken type)
: 1060 mm (width) x 790 mm (length) x 1096 mm (height) *3 (excluding the thread stand)
23 Power consumption 200 VA
24 Mass
Machine head: Approx. 110 kg; Operation panel: Approx. 0.3 kg
Control box: Approx. 4.5 kg
25
Noise
-
Equivalent continuous emission sound pressure level (L
pA
) at the workstation :
A-weighted value of 82.0 dB; (Includes K
pA
= 2.5 dB); according to ISO 10821-
C.6.3 -ISO 11204 GR2 at 2,500 sti/min for the sewing cycle, 3.8 sec. (Pattern :
No.90).
- Sound power level (L
WA
) ;
A-weighted value of 92.5 dB; (Includes K
WA
= 2.5 dB); according to ISO 10821-
C.6.3 -ISO 3744 GR2 at 2,500 sti/min for the sewing cycle, 3.8 sec. (Pattern :
No.90).
*1 : For the machine provided with the optional needle thread clamp unit, the buttonhole length is 10 to 28 mm.
*2 : Parallel section: Taper length can be set to such a value that does not exceed the total of the eyelet section and the
bartacking section.
*3 : The height of the completed unit differs with the height of the table stand.
