1206.GB
D 2
2Battery types
The truck will be equipped with different battery types, depending on the application.
The following table shows which combinations can be included as standard:
The battery weights can be taken from the battery data plate.
Depending on the type of battery used, it is also possible to use models with
enhanced performance or maintenance-free batteries.
F
When replacing or installing batteries, ensure that the battery is correctly secured in
the battery compartment of the truck.
3 Exposing the battery
F
Park the truck securely (see Chapter E).
– Pull lever (1) upward and at the same time set the tiller vertically.
– Release the lever (1) again.
– Flip up the battery latch (2), lift the locking mechanism and open the battery panel
(3).
F
All panels and connections must be restored to the normal operating condition before
the truck can operate again.
24 V PzS battery 3 PzS 420 Ah L
24 V - PzS battery
high performance
3 PzS 450 Ah HX
1
2
3
1206.GB
D 2
2Battery types
The truck will be equipped with different battery types, depending on the application.
The following table shows which combinations can be included as standard:
The battery weights can be taken from the battery data plate.
Depending on the type of battery used, it is also possible to use models with
enhanced performance or maintenance-free batteries.
F
When replacing or installing batteries, ensure that the battery is correctly secured in
the battery compartment of the truck.
3 Exposing the battery
F
Park the truck securely (see Chapter E).
– Pull lever (1) upward and at the same time set the tiller vertically.
– Release the lever (1) again.
– Flip up the battery latch (2), lift the locking mechanism and open the battery panel
(3).
F
All panels and connections must be restored to the normal operating condition before
the truck can operate again.
24 V PzS battery 3 PzS 420 Ah L
24 V - PzS battery
high performance
3 PzS 450 Ah HX
1
2
3
