Jungheinrich ECE 220 User Manual

E 19
1007.GB
5.2 Travel programs
Press the digit keys 1, 2, and 3 to select any of three travel programs. The activated
program is indicated by the green LEDs (23), (24), (25) in the corresponding key.
Z
The travel programmes differ with respect to travelling speed, acceleration, and
deceleration.
Factory settings:
– Program 1: Gentle operation
– Program 2: Normal mode (pre-selected when using the truck for the first time)
– Program 3: Power mode
The travel programs can be adapted individually to the truck (see section 5.4).
5.3 Parameters
In programming mode, the operator keypad enables you to set the code lock
functions and adapt travel programs. In addition, the battery parameters can also be
set.
Z
For trucks without a display instrument (CANDIS (o)) only the code lock parameters
can be set.
Parameter Groups
The parameter number is composed of three digits. The first digit refers to the
parameter group as shown in Table 1. The second and third digits are numbered in
sequence from 00 to 99.
No. Parameter Group
0xx Code lock settings
((codes, travel program authorisation, automatic cutout, etc.)
1xx Travel program 1 parameters
(acceleration, coasting brake, speed, etc.)
2xx Travel program 2 parameters
(acceleration, coasting brake, speed, etc.)
3xx Travel program 3 parameters
(acceleration, coasting brake, speed, etc.)
4xx Program-independent parameters
E 19
1007.GB
5.2 Travel programs
Press the digit keys 1, 2, and 3 to select any of three travel programs. The activated
program is indicated by the green LEDs (23), (24), (25) in the corresponding key.
Z
The travel programmes differ with respect to travelling speed, acceleration, and
deceleration.
Factory settings:
– Program 1: Gentle operation
– Program 2: Normal mode (pre-selected when using the truck for the first time)
– Program 3: Power mode
The travel programs can be adapted individually to the truck (see section 5.4).
5.3 Parameters
In programming mode, the operator keypad enables you to set the code lock
functions and adapt travel programs. In addition, the battery parameters can also be
set.
Z
For trucks without a display instrument (CANDIS (o)) only the code lock parameters
can be set.
Parameter Groups
The parameter number is composed of three digits. The first digit refers to the
parameter group as shown in Table 1. The second and third digits are numbered in
sequence from 00 to 99.
No. Parameter Group
0xx Code lock settings
((codes, travel program authorisation, automatic cutout, etc.)
1xx Travel program 1 parameters
(acceleration, coasting brake, speed, etc.)
2xx Travel program 2 parameters
(acceleration, coasting brake, speed, etc.)
3xx Travel program 3 parameters
(acceleration, coasting brake, speed, etc.)
4xx Program-independent parameters
