1113.GB

E 2

2 Controls and Displays

Item Control / Display

Function

1 Folding operator platform t Pedestrian mode:

– Operator platform in upper position:

Pedestrian travel speed restricted to

max. 4.5 km/h.

Rider mode, operator platform acts as deadman

switch:

– Operator platform in lower position and unladen:

travelling inhibited.

– Operator platform in lower position and laden by

operator (both arms must be folded fully out or in):

travelling released.

2Side arm t When the side arms are not unfolded and the

operator platform is laden and unfolded:

travel speed restricted to max. 6km/h.

3 Collision safety switch t Pedestrian mode:

Safety function which, when activated, forces the

truck to reverse for approx. 3 seconds and then

cuts out until the controller is briefly restored to

neutral.

Rider mode:

No function (optionally with the same function as

pedestrian mode).

4 Controller t Controls travel direction and speed (see

Section 4.2)

5 Tiller t Moving tiller;

Steering and braking:

Set to brake zone (B) (see page E9):

Truck decelerates mechanically.

Set to travel zone (F) (see page E9):

The mechanical brake is released and the truck is

ready for operation.

6 Warning signal (horn) button t Triggers a warning signal.

7 “Lower” button t Lowers load forks.

8 “Lift” button t Raises load forks.

9 Battery discharge indicator t Battery charge status.

10 Display instrument (CanDis) o Operating hourmeter

Displays battery capacity.

Shows the battery residual capacity and the

operating hours completed by the truck

t = Standard equipment o = Optional equipment
