KEB COMBIVERT F0 User Manual

18
4. Steuerteil
4.1 Anschluß der Steuerklemmen
4. Control Circuit
4.1 Connection of Control Terminals
Interne Spannungsversorgung / Internal Voltage Supply
Externe Spannungsversorgung / External Voltage Supply
Ansteuerung Parametereinstellung
Activation Parameter Setting
o.13 H.0 H.1
P1 0…+10 VDC 3 (2) 0 0
(1) 0…±10 VDC 4 3 0
(2) 0…+10 VDC 3 (2) 0 2
(3) 0…20 mADC 3 (2) 1 2
(4) 4…20 mADC 3 (2) 2 2
3...10 kΩ
+
+
20...30VDC ±0%
max. 3,6 V
SS
0...20 mA DC (3)
4...20 mA DC (4)
+
+
0...±10 VDC (1)
0...+10 VDC (2)
1234567891011121314151617181920212223
RLA RLB RLC GND I1 I2 I3
REF
1
REF
2
FR
OUT
1
0V
+15VFRQ CRF
REF
COM ST
RST
FLA FLB FLC
Poti
P1
3...10 kΩ
+
0...20 mA DC (3)
4...20 mA DC (4)
+
+
0...±10 VDC (1)
0...+10 VDC (2)
1234567891011121314151617181920212223
RLA RLB RLC GND I1 I2 I3
REF
1
REF
2
FR
OUT
1
0V
+15VFRQ CRF
REF
COM ST
RST
FLA FLB FLC
Poti
P1
2. Sollwert
2nd set value
2. Sollwert
2nd set value
