6517B-900-01 Rev. A / Jun 2008 Return to Section Topics 4-7
Model 6517B Electrometer User’s Manual Section 4: Measurement Options
6. A numeric parameter is keyed in by placing the cursor on the digit to be changed, and
pressing the RANGE keys ( and ) to increment or decrement the digit.
7. A change is only executed when the ENTER key is pressed. Entering an invalid parameter
generates an error, and the entry is ignored. Changes are also ignored if an EXIT is
performed.
8. The INFO key can be used anywhere in a menu to display helpful information messages
concerning operation. To cancel an information message and remain in the menu, press
INFO a second time, EXIT, or ENTER. Pressing a function key cancels INFO and the menu,
and returns the instrument to a reading display.
Voltage source
The built-in, bipolar, 1W voltage source can output up to ±1000V. With the instrument in the normal
measurement mode, the programmed V-Source level is shown on the bottom line of the display.
Connections
If used as an independent source, voltage is availa
ble at the V-SOURCE HI and LO terminals on
the rear panel (see Figure 4-2). If used as an FVMI (force voltage measure current) source,
V-Source LO can be internally connected to amm
eter LO from the METER CONNECT option of
the CONFIGURE V-SOURCE menu (see C
onfiguring V-Source for more information). Figure 4-3
shows the connections for this configuration.
Table 4-5
Menu summary
Action Description
CONFIG-(function)
MENU
or
RANGE
RANGE
ENTER
EXIT
INFO
Press the CONFIG key, then a function key (for example,
V) to view the top level of a function configuration
menu.
Press the MENU key to view the top level of the main
menu; the operations that have no corresponding
key are included in the main menu.
Use the cursor keys to move the highlighted cursor
among menu selections, or the digits of a parameter
value, or change channels on the scanner.
Use the RANGE keys to increment and decrement digits
of a parameter value.
Accepts menu selection or data entry.
Cancels menu selection changes and returns to the
display of the previous menu level.
Displays context-sensitive information about the present
menu level; toggles information message on/off.
WARNING Hazardous voltages may be present on the output and guard terminals. To
prevent electrical shock that could cause injury or death, NEVER make or
break connections to the Model 6517B while the output is on. Power off the
equipment from the front panel or disconnect the main power cord from the
rear of the Model 6517B before handling cables connected to the outputs.
Putting the equipment in standby mode does not guarantee that the outputs
are not powered if a hardware or software fault occurs.
