CABIN (if installed) 13-5
069OD10A069OD09A069OD08A
HEATER
(1) Heater Switch
HEATER SWITCH
Turning the switch to “LOW” or “HIGH”
operates it.
WARNING
After driving with warm air, place
the heater switch at “LOW”
position. Wipe off the indoor win-
dow if it becomes blurred.
Make sure that nothing will block
the entrance of the heater grill. It
is the cause of fault.
(1) Warm Air Outlet
ADJUSTMENT OF THE DIRECTION OF
THE WIND
The direction of the warm wind can be
adjusted forward, backward, left and
right.
HINTS FOR HEATER USE
1. Please use antifreezing solution suit-
able for the external temperature in
winter.
2. Check the heater hose before using.
AIR CONDITIONER
(1) Wind Volume Adjusting Switch
(2) Temp. Adjusting Lnob (3) Cold Air Outlet
You can adjust wind volume three stages
as “LOW”, “MEDIUM”, “HIGH”. If you turn
the right switch clockwise, you can ad-
just the room temperature.
ADJUSTMENT OF THE DIRECTION OF
THE AIR
You can freely adjust the direction of the
air by turning the grill.
