UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and
controls. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Fuel-Level
Engine Coolant-Temperature
Diesel Preheat/Glow Plugs
(Low Temperature Start Aid)
Parking Brake
Battery Charging Condition
Engine Oil-Pressure
Turn Signal
Power Take-Off Clutch
Control-Off Position
Power Take-Off Clutch
Control-On Position
Differential Lock
Position Control-Raised
Position
Position Control-Lowered
Position
Hazard Warning Lights
Master Lighting Switch
Position Lamps
Headlight-Low Beam
Headlight-High Beam
Audible Warning Device
Four-Wheel Drive-ON
Four-Wheel Drive-OFF
Slow
Fast
Coolant Level
T/M Oil Filter
