TP-6881 7/15 63Section 4 Troubleshooting
4.10 Status Messages
The following messages are displayed to show system
status. Notices are displayed in the Event History in
SiteTech when active but do not appear on the controller
display. Some status messages are displayed when a
digital input is activated; the optional Programmable
Interface Module (PIM) is required for display of those
messages as noted in the table.
Status Message Action Description/ Comments Check
Always Off * Notice
OnCuer Plus has been used to control
this PIM digital output. The digital output
is no longer controlled by the generator
set.
Applies to digital outputs B3 through B6
on the PIM only.
Click on the PIM output in
OnCue Plus to turn the output
on or off. See the OnCue
Plus Operation Manual.
To reset the PIM digital output
to a function controlled by the
generator set, use SiteTech
software to re-assign the
output event.
Always On * Notice
Auto Locked *
(Chicago Code Active)
Notice The digital output for Chicago Code
Active (PIM) is active (contacts closed),
indicating the digital input for Chicago
Code Active (PIM) is active (low) and
thus master switch is locked in the AUTO
position.
Check customer equipment
connected to the PIM module.
Common Fault Notice The digital output for Common Fault
(PIM) is active (contacts closed),
indicating the generator is shutdown for
any (all) fault.
Check for faults and
troubleshoot any/all fault
conditions individually.
Common Warng Notice The digital output for Common Warning
(PIM) is active (contacts closed),
indicating that any (all) warning is active.
Check for warnings and
troubleshoot any/all warning
conditions individually.
Default Pars Warning
(Default Parameters)
Warning The controller has been loaded with
default parameters.
Configure settings as required
for desired operation.
Emerg Pwr On
(Emergency Power System
Supplying Load)
Notice The digital output for EPS Supplying
Load (PIM) is active (contacts closed),
indicating there is current output (>5%)
from the alternator, only if CTs are
installed.
Nothing to check.
Eng Cooldown Notice The digital output for Engine Cooldown
Active (PIM) is active (contacts closed),
indicating the generator is running in
cooldown. (Delay 5 min.)
Check remote start circuit if it
was expected that the
generator should be running.
Consult ATS operations
manual.
Fuel Spill * Notice The digital output for Fuel Spill (PIM) is
active (contacts closed), indicating any of
the digital inputs for Fuel Tank Leak
Warning, Fuel Tank Leak Shutdown,
Engine Fuel Level Warning or Engine
Fuel Level Critically High (PIM) is active
(low).
Check customer equipment
connected to the PIM module.
* Programmable Interface Module (PIM) required.
[ Load management device required (LCM, load shed kit, or RXT with combined interface/ load management board).
